Ultimate Guide to TPO Waterproofing Membrane

TPO waterproofing membrane is a high-performance flexible sheet produced using advanced polymer processing technology. It is made from thermoplastic polyolefin (TPO), a blend of ethylene-propylene rubber and polypropylene, offering excellent weather resistance and weldability.

Reinforced with a polyester mesh fabric, the membrane provides outstanding tensile strength and durability. Its light-colored, smooth, and reflective surface improves energy efficiency by reducing heat absorption.

As a chlorine-free and eco-friendly material, it promotes safer and more sustainable construction. Heat-welded seams ensure a strong, watertight bond for long-lasting protection.

Industry-specific attributes:

Other attributes:



Attribute	Value
Place of Origin	Shandong, China
Warranty	1 Year
Material	TPO
Feature	Water resistant, Anti-aging, High Strength, Eco Friendly
Shape	ROUND
Roofing product type	Roofingfelt
Brand Name	Huafeng
Model Number	1.2mm 1.5mm 1.8mm
Product Name	Thermoplastic Polyolefin Waterproofing Membrane
Usage	Building Materials and Real Estate
Feature	Waterproof
Packing	Plastic outer packaging
MOQ	1000 Square Meter
Weight	25KG
Shape	Columnar

The material inherits the long-term weather resistance and durability of ethylene-propylene rubber while retaining the weldability of polypropylene. The addition of a polyester fiber layer between two TPO layers enhances its physical properties, significantly improving tensile strength, fatigue resistance, and puncture resistance.

Serial number	Item	Indicator
		H	L	P
1	Minimum resin layer thickness on middle fabric (mm): ≥	——	——	0.40
2 Tensile Strength	Maximum Tensile Force (N/cm) ≥	——	200	250
	Tensile Strength (MPa) ≥	12.0	——	——
	Elongation at Maximum Force (%) ≥	——	——	15
	Elongation at Break (%) ≥	500	250	——
3	Dimensional Stability (Heat Treatment) (%) ≤	2.0	1.0	0.5
4	Low Temperature Flexibility	No cracking at -40℃
5	Water Impermeability	0.3MPa water pressure, 2 hours – no leakage
6	Impact Resistance	0.5kg·m impact – no water penetration
7	Static Load Resistance	——	——	20kg static load – no water penetration
8	Peel Strength (Seam Joint) (N/mm)	≥4.0 N/mm or membrane failure	3.0
9	Tearing Strength (Right Angle) (N/mm)	60	——	——
10	Trapezoidal Tear Strength (N/mm)	——	250	450
11	Water Absorption (70℃, 168h) (%) ≤	4.0
12 Heat Aging (115℃)	Duration	672h
	Appearance	No blistering, cracking, delamination, adhesion, or holes
	Tensile Force Retention Rate (%) ≥	——	90
	Tensile Strength Retention Rate (%) ≥	90	——	——
	Elongation at Maximum Force Retention Rate (%) ≥	——	——	90
	Elongation at Break Retention Rate (%) ≥	90	90	——
	Low Temperature Flexibility	No cracking at -40℃
13Chemical Resistance	Appearance	No blistering, cracking, delamination, adhesion, or holes
	Tensile Force Retention Rate (%) ≥	——	90	90
	Tensile Strength Retention Rate (%) ≥	90	——	——
	Elongation at Maximum Force Retention Rate (%) ≥	——	——	——
	Elongation at Break Retention Rate (%) ≥	90	90	——
	Low Temperature Flexibility	No cracking at -40℃
14Artificial Weathering (Accelerated Aging)	Duration	1500h
	Appearance	No blistering, cracking, delamination, adhesion, or holes
	Tensile Force Retention Rate (%) ≥	——	90	90
	Tensile Strength Retention Rate (%) ≥	90	——	——
	Elongation at Maximum Force Retention Rate (%) ≥	——	——	90
	Elongation at Break Retention Rate (%) ≥	90	90	——
	Low Temperature Flexibility	No cracking at -40℃
a) Static Load Resistance (required only for mechanically attached roofing membranes) b) For single-ply roofing systems, the required artificial weathering test duration is 2,500 hours.

It is primarily designed for permanent, high-performance waterproofing applications on roofs of various types, including industrial, civil, and public buildings.
